220/380V Industrial Steam Generator , Stainless Steel Mini Steam Generator

Name: 220380V Industrial Steam Generator Stainless Steel Mini Steam Generator
Brand: ZHAN YAN
Price: 1 USD

Buy cheap 220/380V Industrial Steam Generator , Stainless Steel Mini Steam Generator product

Place of Origin : Shanghai, China (Mainland)

Brand Name : ZHAN YAN

Certification : CE Certificate

Supply Ability : 30 Set/Sets per Month

Packaging Details : 1.For packing, generally we use wood box outside as the pictures shows, with pallet. 2.Generally size around 2100*850*2000mm(min),Up to model.the big kinds can reach 3700*1314*2200mm. 3.Weight range from 600kg to 4 T, pls confirm accurate transport

MOQ : 1 Set/Sets

Price : Negotiable

After-sales Service Provided : Engineers available to service machinery overseas

Application : Beverage, Chemical, Commodity, Food, Medical

Packaging Material : Wood, Glass ,Metal , Plastic

Type : Other, Other

Condition : New

Packaging Type : Bottles, Cans

Automatic Grade : Automatic

Driven Type : Electric

Voltage : 220/380V, 220/380VAC, 50/60Hz

Power : UP TO MODEL

Weight : Up to model

Dimension(L*W*H) : UP TO MODEL

Product name : Steam Generator For Sleeve Labeling Machine

Function : Packaging

Packing material : Wooden case

Material : 304 Stainless Steel

Usage : Food, Beverage,Commodity

Name : Sleeve Labeling Machine

Port : SHANG HAI

Contact Now

Factory Sale Compact Industrial Mini Steam Generator

Efficient Juice Drink Bottle Electric Steam Generator

Specification Parameters	18KW	24KW	36KW	48KW
Steam generating (Kg/h)	24	32	48	64
Steam pressure (Mpa)	0.4/0.7	0.4/0.7	0.4	0.4
Steam temperature (°C)	151/170	151/170	151	151
Power (KW)	18	24	36	48
Motor power (w)	550	750	750	750
Diameter of safety valve	DN15
Diameter of main steam valve
Diameter of drain valve
Diameter of water supply valve
Boiler Water volume (L)	42
Appearance sizes (mm)	6305501400	7206501350	10306301350	10306301350
Total weight(KG)	85	90	195	195

Advantages

1. Stainless steel 304 of host machine by all cover: simple, athleticm,beautiful apperance.
2. compact, lightweight H - type design, won a number of national patents.
3. High thermal efficiency, rapaid warming, thus saving energy and operating costs.
4. A high degree of automation, fuzzy control module, agreat conveience for users.
5. H - type electric heating steam generator has variety protection: pressure protection, alow level alarm, overpressure protection. Outgoing ago,,also for 1.5 times the rated pressure experiments
6. Drive system: with high power of Servo Motor,more forceful.
7. Modular design, demolition convenient,user - friendly maintenance.

220/380V Industrial Steam Generator , Stainless Steel Mini Steam Generator

ZYP Sleeve Labeling Machine
Models	ZYP-100M	ZYP-200M	ZYP-300M	ZYP-300H	ZYP-400H	ZYP-260M	ZYP-220M
Capacity(b/m)	100~150	170~230	220~300	270~300	350~400	500	2*170~230
Diameter (mm)	Ø25- Ø120
Label material	PVC PET OPS
Label thickness(mm)	0.03-0.13mm
Dimension(L×W×H)(m)	2.20.852.1	2.20.852.1	2.50.852.2	2.50.852.2	2.50.852.2	3.21.22.1	3.21.22.1
Gross weight(kg)	550	550	600	700	700	1000	1000

220/380V Industrial Steam Generator , Stainless Steel Mini Steam Generator

Shanghai Zhanyan Packing Machinery Co.,Ltd. ,professional manufacturer packing machinery has always devoted to the research,development and manufacturing full automatic packing machines and shrink sleeve labeling machine,shrink tunnels in such fields as foodstuff,beverage,commodity etc. The machine are widely used for packing fruit juice,tea drinks,commodity,purified water,condiments,beer,sport drinks and comestics,suitable to various types of bottles.

Based on the principle of“Quality gains clients,Credibility creates porfits”Zhanyan carries out the spirits of perfect production. Aiming at demands of customers,Zhanyan manufacture satisfying equipments for the market, going to the international market with high speed and good performance machines.

220/380V Industrial Steam Generator , Stainless Steel Mini Steam Generator

We promise to offer you satisfactory services within the shortest time,in details:

1.Senior after-service engineersof our company will offer you regular technical services;

2.Specialized department and management personnel responsible for after services,large amounts of parts and fittings are available;

3.Complete after-service system and outstanding quality assure you of satisfaction and easement.

220/380V Industrial Steam Generator , Stainless Steel Mini Steam Generator

1.Q: What's your main products?

A: we produce ZYP-series sleeve labeling machine and HLML-series OPP labeling machine;

2.Q: Are you factory?

A: Yes, we are manufacturer,our factory located in Shanghai(Add:NO.158-F Huiping Road,Nanxiang High-tech Industrial Park,Jiading district,Shanghai);

Our new factory in Taicang city (Jiangsu Province) is under construction now;

3.Q: If I have special needs for design about the bottles label and machine,can you do that for me?

A: we can design under your needs, based on the bottles /label sample, we also can supply plant engineering service for you;

4.Q:How about your after-sale service?

A: we have professional technical department to ensure the machine functioning well, both hardware and software technology;

5.Q:Can we visiting your factory and production site?

A: we really welcome your visiting, as the pictures above show, in the past years, many customers from all over the world visited and cooperated with us.

We wish we can provide the best packing labeling machine and service for you.
